Eaton DILM Replacement Coil Selection Guide: Complete Voltage Range
Selecting the correct replacement coil ensures reliable contactor operation. This 2026 guide covers the complete Eaton XSP coil catalog from 24V to 600V for all DILM frame sizes.
1. Why Replacement Coils Matter
Replacement coils are essential for:
- Restoring contactor operation after coil burnout
- Upgrading to different control voltages without replacing entire contactor
- Preventing unplanned downtime in industrial facilities
- Cost-effective maintenance vs full contactor replacement
2. AC Coil Voltages
Common AC coil voltages stocked at RF Mando:
- Low voltage: 24V, 42V, 48V AC
- Standard European: 110V, 115V, 120V, 220V, 230V, 240V AC
- High voltage: 380V, 400V, 415V, 480V, 500V, 600V AC
- Frequencies: 50Hz, 60Hz, dual-frequency
3. DC Coil Voltages
DC coils for battery or solar applications:
- 24VDC, 48VDC, 60VDC, 110VDC, 120VDC, 220VDC, 240VDC
4. Compatibility by Frame Size
- DILM17-DILM38: XSP standard coil frame
- DILM40-DILM65: XSP medium coil frame
- DILM80-DILM150: XSP medium-large coil frame
- DILM185-DILM250: XSP large coil frame
- DILM400-DILM1000: XSP extra-large coil frame
5. Selection Procedure
- Identify contactor frame size from nameplate
- Verify original coil voltage rating
- Select replacement XSP coil matching voltage
- Verify coil part number matches series
6. RF Mando Stock and Pricing
RF Mando stocks complete XSP replacement coil inventory:
- DILM17-38 XSP: $100
- DILM40-65 XSP: $120
- DILM80-150 XSP: $150-$250
- DILM400-1000 XSP: $250-$320
MOQ 500 pieces. Lead time 15 days.
【Contact: Joanna@rfmando.com / WhatsApp: +86 189 6031 3731 / Website: https://www.rfmando.com/】
