Reading the Designation One More Time
DILM25-10: 25A frame, 10A AC-3 rating, with a 230V AC coil in the base designation. This is the mainstream 230V single-phase-supply frame in European panel work, and it is the version most often specified when an incumbent brand is being re-sourced for price.
The variables that decide whether an alternative is a like-for-like replacement: frame size (25A), AC-3 rating, coil voltage (230VAC), auxiliary contact count, and terminal layout. Change any one of those and you have a different part, not a substitute.
Cross-Reference Table for Panel Builders
| Parameter | DILM25-10 230V equivalent | What to verify before substituting |
|---|---|---|
| Frame / current | 25A frame | Incumbent frame current must match or exceed the load |
| AC-3 rating | 10A at 400/415V | Compare AC-3, not AC-1 — they are not the same number |
| Coil voltage | 230VAC | Confirm the panel control supply, not the load voltage |
| Auxiliary contacts | 1NO standard | Add-on blocks are a separate SKU |
| Terminals | Screw terminals | Check conductor size against your panel wire gauge |
| Mounting | DIN rail | Verify available enclosure depth |
Why Distributors Re-Source This Frame
The honest reason is margin on a high-turnover part. The honest risk is that a substitution with a different auxiliary contact count or a different terminal arrangement turns a five-minute swap into a panel rework. The way to avoid that is to fix the specification before you shop the price: write down the frame, the AC rating, the coil voltage, and the aux count, then request quotes against that frozen specification.
Catalogue references for the specification above: RF Mando Eaton DILM4M115 (230V 50Hz / 240V 60Hz) contactor and RF Mando TOMZN TOCT1 4P 63A DIN-rail contactor. Both are MOQ-based, ship on our own PCBA and housing tooling, and one free sample per SKU is available before you commit to a production order.
Our Commercial Terms
- MOQ: 500 pcs per SKU.
- Lead time: 7 days from existing tooling, 15 days for a new aux variant.
- QC: 100% functional test; third-party QC report at AQL 5% available on request.
- Certification: CE-RED, RoHS; batch date codes and carton-level packing lists.
- Payment: T/T 30/70. Prices EXW Xiamen.
Trademark Compliance
Eaton and DILM are trademarks of Eaton Corporation plc. We manufacture compatible replacements with our own tooling and our own design, are not an authorised Eaton distributor, and do not apply Eaton branding to our goods. Where a project specification requires an authorised-channel part, that part must come from Eaton.
Need a Quotation?
Send us the brand and model you need to replace, plus your target monthly quantity. We reply with the exact part number, EXW price, MOQ and lead time.
- Email: Joanna@rfmando.com
- WhatsApp / Telegram: +86 189 6031 3731
- Website: https://www.rfmando.com/
All prices EXW Xiamen (China). MOQ 500 pcs per SKU for trial orders. Sample: 1 free unit per SKU (buyer covers $30 DHL). Payment T/T 30/70.
