What This Block Actually Does
An auxiliary contact block does not switch the load. It mirrors the contactor's state as a low-current signal so a control circuit or a PLC input can see what the main contacts are doing. The 1NO + 1NC arrangement in this block family gives you both a normally-open and a normally-closed indication from one attachment, which is what lets one contactor signal "running" and "stopped" without a second sensing device.
That is why aux blocks are ordered by the pair rather than the single — a panel that has been re-sourced on the contactor usually has an equal or larger number of aux blocks to re-source alongside it.
Compatibility Parameters That Decide Fit
| Parameter | Specification | Why it matters |
|---|---|---|
| Contact arrangement | 1NO + 1NC | Determines whether your PLC logic works unchanged |
| Mirror contact | Yes, on the NC side | Required for safety applications and for mirror-contact diagnostics |
| Rated auxiliary current | see product sheet | Signal current, not load current — do not conflate the two |
| Width on DIN rail | single module width | Decides whether it fits the remaining panel space |
| Mechanical coupling | snap-fit to contactor side | Must engage positively; a loose fit causes intermittent signals |
| Terminal type | screw terminals | Match your panel conductor size |
Catalogue references for the specification above: RF Mando DILM150C-XHI22 auxiliary contact block and RF Mando DILA-XHI22 auxiliary contact module (XTCEXFAC22). Both are MOQ-based, ship on our own PCBA and housing tooling, and one free sample per SKU is available before you commit to a production order.
Ordering Pattern We See From Distributors
The common pattern is a mixed order: contactor frames plus aux blocks in a 1:1 or 1:2 ratio, sometimes with a few different frame sizes in the same carton. That is fine for us and it is worth stating explicitly — mixed-SKU cartons are normal, and we will produce a carton-level packing list that breaks out quantities by SKU so your receiving team can put the right parts on the right shelf.
Terms and Compliance
- MOQ: 500 pcs per SKU.
- Lead time: 7 days from existing tooling.
- QC: 100% functional test, AQL 5% third-party report on request.
- Payment: T/T 30/70, EXW Xiamen.
Eaton and DILM are trademarks of Eaton Corporation plc. Our auxiliary contact blocks are independently engineered replacements using our own design and tooling. We are not an authorised Eaton distributor and do not reproduce Eaton trademarks on our products.
Need a Quotation?
Send us the brand and model you need to replace, plus your target monthly quantity. We reply with the exact part number, EXW price, MOQ and lead time.
- Email: Joanna@rfmando.com
- WhatsApp / Telegram: +86 189 6031 3731
- Website: https://www.rfmando.com/
All prices EXW Xiamen (China). MOQ 500 pcs per SKU for trial orders. Sample: 1 free unit per SKU (buyer covers $30 DHL). Payment T/T 30/70.
